Input parameters: Single phase, AC220V±10% ,50HZ
Output parameters: DC 0~12V 0~10A
Output mode: Common DC output
Cooling method: Air cooling
Power supply type: IGBT-based high frequency power supply
Application Industry: Plating industry, such as gold, silver and jewelry plating.
Characteristic Types |
Parameter Items |
Technical Requirements |
| Power Types | Power types | High-frequency Power Supply |
| Model and specifications | TBFBZ-10A/12V | |
| Cooling mode | Air-cooled | |
| Switch tube type | IGBT | |
| Input Characteristics | Rated Input Voltage | Single phase, AC220V±10% ,50HZ |
| Rated Input Power | 0.12KVA | |
| Rated Input Current | AC 0.16A | |
| Input Power Factor | COSΦ≥0.95 | |
| Output Characteristics | Output Voltage | DC 0～12V |
| Output Current | DC 0～10A | |
| Stabilized Current Precision | ≤1%（Rated Current) | |
| According to accuracy | 0.1A，0.01V | |
| Rated Output efficiency | ≥91% | |
| Environmental Conditions | Installation site | Indoor installations |
| Altitude | ≤2000 meters | |
| Ambient temperature | -20℃～40℃ | |
| Relative humidity | ≤90％ | |
| Control Mode | Operating mode | PLC, ADDA, Ethernet, RS485 and RS232 |
| Weight | Net weight | About 15KG |
| External Dimension | Height*Width*Depth | H210mm×W150mm×D350mm |
| Protection Characteristics | With over voltage, over current, overload, short circuit, overheating and other abnormal self-protection function | |
| Application | Model | Output Parameters |
| 220V Single phase input | HIFB-500A4V | 4Vdc/500A |
| TBFBZ-600A4V | 4Vdc/600A | |
| HMFB-10A5V | 5Vdc/10A | |
| HMFB-20A5V | 5Vdc/20A | |
| TBFBZ-25A5V | 5Vdc/25A | |
| TBFBZ-400A5V | 5Vdc/400A | |
| HMFB-600A5V | 5Vdc/600A | |
| HMFB-800A5V | 5Vdc/800A | |
| HMFB-2A6V | 6Vdc/2A | |
| HMFB-3A6V | 6Vdc/3A | |
| HMFB-350A6V | 6Vdc/350A | |
| HMFB-5A6V | 6Vdc/5A | |
| HMFB-10A6V | 6Vdc/10A | |
| TBFB-50A6V | 6Vdc/50A | |
| HMFB-600A6V | 6Vdc/600A | |
| TBFBZ-1A9V | 9Vdc/1A | |
| TBFB-10A9V | 9Vdc/10A | |
| TBFBZ-20A9V | 9Vdc/20A |
