0~5V 0~50A Water-cooled IGBT Rectifier

Specifications

Input parameters: Single phase, AC220V±10% ,50HZ

Output parameters: DC 0~5V 0~50A

Output mode: Common DC output

Cooling method: Water cooling

Power supply type: IGBT-based high frequency power supply

Application Industry: Plating industry

Description

Electroplating is the process of applying a thin layer of other metals or alloys on the surface of certain metals by electrolysis. It is a process of applying a metal film to the surface of metals or other materials to prevent metal oxidation (such as rust), improve wear resistance, electrical conductivity, reflectivity, corrosion resistance (copper sulfate, etc.) and enhance aesthetics.

Technical Parameters:

Characteristic Types	Parameter Items	Technical Requirements
Power Types	Power types	High-frequency Power Supply
	Model and specifications	TBSBZ-50A/5V
	Cooling mode	Water-cooled
	Switch tube type	IGBT
Input Characteristics	Rated Input Voltage	Single phase, AC220V±10% ,50HZ
	Rated Input Power	0.12KVA
	Rated Input Current	AC 0.16A
	Input Power Factor	COSΦ≥0.95
Output Characteristics	Output Voltage	DC 0～5V
	Output Current	DC 0～50A
	Stabilized Current Precision	≤1%（Rated Current)
	According to accuracy	0.1A，0.01V
	Rated Output efficiency	≥91%
Environmental Conditions	Installation site	Indoor installations
	Altitude	≤2000 meters
	Ambient temperature	-20℃～40℃
	Relative humidity	≤90％
Control Mode	Operating mode	PLC, ADDA, Ethernet, RS485 and RS232
Weight	Net weight	About 15KG
External Dimension	HeightWidthDepth	H247mm×W130mm×D468mm
Protection Characteristics	With over voltage, over current, overload, short circuit, overheating and other abnormal self-protection function

Optional models:

Application	Model	Output Parameters
220V Single phase input	HIFB-500A4V	4Vdc/500A
	TBFBZ-600A4V	4Vdc/600A
	HMFB-10A5V	5Vdc/10A
	HMFB-20A5V	5Vdc/20A
	TBFBZ-25A5V	5Vdc/25A
	TBFBZ-400A5V	5Vdc/400A
	HMFB-600A5V	5Vdc/600A
	HMFB-800A5V	5Vdc/800A
	HMFB-2A6V	6Vdc/2A
	HMFB-3A6V	6Vdc/3A
	HMFB-350A6V	6Vdc/350A
	HMFB-5A6V	6Vdc/5A
	HMFB-10A6V	6Vdc/10A
	TBFB-50A6V	6Vdc/50A
	HMFB-600A6V	6Vdc/600A
	TBFBZ-1A9V	9Vdc/1A
	TBFB-10A9V	9Vdc/10A
	TBFBZ-20A9V	9Vdc/20A
